User Interface Commands
FOT Lab Kit User’s Manual 4-5
Table 4-1 Summary Listing of Parameter Commands
Table 4-2
Summary Listing of Action Commands
Command Code Command Description
AE Analog Output Enable Enable/Disable Analog Outputs
AO Analog Output Set Analog-Output Temperature Offset Factor
AS Analog Scaling Factor Set Analog-Output Temperature Scaling Factor
CC Calibration Correction Enable/Disable Application of Calibration Factors
CT Calibration Set Calibration Temperature for Auto-Calibration Function
DF Data Format Set Serial Data Output Format
DS Data String Capture User Data Sequence
HL High Temperature Limit Set High Temperature Limit (obsolete, no longer supported)
ID Information Display Report Device ID and Current Parameter Settings
LL Low Temperature Limit Set Low Temperature Limit (obsolete, no longer supported)
MU Measurement Update Set Interval Between Temperature Measurement Reports
PS Probe Select Specify Active-Input List
SL Signal Level Report LED Light Source Intensity Level
SM Sample Measurement Set Number of Samples to be Retained Per Measurement
SN Serial Number Report Device's Serial Number
ST STart up Mode Select Startup Mode
SV Save Parameters Save Current User Parameters and Calibration Factors
TU Table Selection Reports the Currently Selected Look-up Table
UN Output Units Specify Output Units of Measure
Command Code Command Description
CTRL + A
Abort (01h) Abort calibration sequence in progress
CTRL + D
Disable (04h) Disable remote control of temperature reporting
CTRL + E
Enable (05h) Enable remote control of temperature reporting
CTRL + F
Flush (06h) Flush the measurement buffer
CTRL + I
Initiate (09h) Begin data sampling
CTRL + K
Calibrate (0Bh) Begin auto-calibration sequence
CTRL + Q
Report (11h) Report the most recent measurement / enable serial output
CTRL + S
Stop (13h) Disable serial data output
CTRL + T
Standby (14h) Enter standby mode
CTRL + X
Reset (18h) Reset the instrument
