The rear panel mode LEDs for Link Act/PoE mode are the same as the front
Port LEDS
Link Activity
On The Link/Activity LED of the port will be on if there is a
device connected to the port
Flashing The Link/Activity LED fl ashes when a port is receiving or
transmitting data
Off There is nothing connected to the port
PoE
On Connected device is receiving PoE power
Off Connected device is not receiving PoE power
Flashing PoE fault (i.e. problem with Ethernet cable or PoE device)
Rear
Speed/
Link/Act
Green The Link/Activity LED of the port will be on if there is a
1000Mbps device connected to the port
Amber The Link/Activity LED of the port will be on if there is a
10/100Mbps device connected to the port
Flashing The Link/Activity LED fl ashes when a port is receiving
or transmitting data
Off There is nothing connected to the port
PoE
On Connected device is receiving PoE Power
Off Connected device is not receiving PoE power
Green Power being supplied within PD Specifi ed limits
Amber Power exceeds PD Specifi ed limits
Amber Flashing PoE Fault( i.e. problem with Ethernet cable or PoE device)
