PACKAGE CONTENTS
The following items are included in the box:
XMS-2624P 26-Port/24 PoE+ Gigabit Managed Switch
Power Cord
Rack Mount brackets and screws
Four rubber pads
Quick Installation Guide
If any of the listed items are missing or damaged, please contact the Distributor
from whom you purchased for return/replacement.
HARDWARE DESCRIPTION
Front Panel
The front panel of the XMS-2624P Switch includes 1 console port, 24 Gigabit RJ45
Ports and 2 RJ45/SFP combo ports for expansion, as well as LED indicators for each
port. Each Gigabit port has one Link/Activity/PoE LED. A push button switch with
an LED indicator switches the display between Link/Activity and PoE.
XMS-2624P Front Panel View
LED Indicators
Each port has one Link/Activity/PoE LED. A push button switch with LED indicator
switches the display between Link/Activity and PoE.
