Utility Requirements
11
GFI Outlet
Electrical Requirements for Built-in Unit
s:
Installation should include an outdoor 120VAC 15A GFI electrical outlet located adjacent
to the grill. Do not locate motor or outlet on the same side as a Side Burner unless a minimum
of 12” clearance is provided. Simply plug in the electrical cord from the transformer provided,
into a GFI equipped outdoor outlet.
Professional Models Only: The power source should be a GFI outlet for plugging in the cord
from the transformer (supplied). The transformer reduces the voltage to 12 Volts for the light and
rotisserie motor. A qualified electrician can install a GFI outlet inside the island enclosure for
built-in units. The transformer has 2 output leads with jackplugs on the end. These jackplugs
must be plugged in to the 2 female jacks mounted on the bottom rail of the grill on the lower left
side approximately half way towards the rear of the unit*. The 2 jackplugs are interchangeable
and can be plugged in to either of the female jacks. These supply the power to the light and
rotisserie motor jack.
Rev. 04/2005
WARNING
Electrical Grounding Instructions:
This outdoor cooking gas appliance is equipped with a
three-prong (grounding) plug for your protection against
shock hazard and should be plugged directly into a properly
grounded three-prong receptacle. Do not cut or remove the
grounding prong from this plug.
A
VERTISSEMENT
Instruction pour la mise à la terre electrique.
Cet appareil est muni d’une fiche à trois broches (mise
à la terre) afin de vous protéger des chocs et doit être
branché directement dans une prise de courant à trois
broches adéquatement mise à la terre. Il ne faut pas
couper ou enlever la broche de mise à la terre de cette
fiche.
Plug jacks in here
Transformer jacks
Professional Series Units
*Plug both output jacks from the transformer
into the panel mounted on left side of grill.
