M-Audio Venom

Appendix B: System Exclusive Implementation
102
Venom User Guide
Arpeggiator Header Data Dump
When an Arpeggiator Edit buffer data is recalled the following data is sent as part of the SysEx:-
Parameters can also be individually updated using the appropriate address.
*** Off/On is determined by evaluating the CC value received. If the CC value is 63 or lower, the state is “Off.” If it is 64 or higher,
the state is “On.”
Global Parameters Data Dump
When a Global data is recalled the following data is sent as part of the SysEx:
Parameters can also be individually updated using the appropriate address.
Addr [H] Parameter Name Range
00 00 ArpPatch.Enable Off/On ***
00 01 ArpPatch.ArpSrc_f Off/On ***
00 02 ArpPatch.Bank 0 ~ 1
00 03 ArpPatch.Pattern 0 ~ 127
00 04 ArpData.ArpMode 0 ~ 2
00 05 ArpData.NoteOrder 0 ~ 4
00 06 ArpData.OctaveRange -4 ~ +4
00 07 ArpData.BiPolar Off/On ***
00 08 ArpData.LatchKeys Off/On ***
00 09 ArpData.RootNote 0 ~ 127
00 0A PatchName [0] 0 ~ 127
00 0B PatchName [1] 0 ~ 127
00 0C PatchName [2] 0 ~ 127
00 0D PatchName [3] 0 ~ 127
00 0E PatchName [4] 0 ~ 127
00 0F PatchName [5] 0 ~ 127
00 10 PatchName [6] 0 ~ 127
00 11 PatchName [7] 0 ~ 127
00 12 PatchName [8] 0 ~ 127
00 13 PatchName [9] 0 ~ 127
Addr [H] Parameter Name Range
00 00 Octave 61-68 (-3 ~ +3)
00 01 Transpose 48-72 (-12 ~ +12)
00 02 MasterTune 14-114 (-50 ~ +50)
00 03 MasterTempo 50 ~ 300
00 04 GlobalChan 0 ~ 15
00 05 MidiOutMode 0 ~ 1
00 06 LocalMode 0 ~ 1
00 07 VelCurve 0 ~ 3
00 08 FixedVel 1 ~ 127
00 09 MidiReceiveClockMode 0 ~ 2
00 0A MidiTransmitClockMode 0 ~ 2
00 0B MidiSingleSel_f Off/On ***
00 0C MidiMultiSel_f Off/On ***
00 0D ArpegRoute 0 ~ 1
00 0E SustainPedal CC 0 ~ 134
00 0F ExpresssionPedal CC 0 ~ 131
