Chapter 5: Advanced Synthesizer and Effects Editing
56
Venom User Guide
Volume
The Master Volume gain stage follows the Master EQ. This gain stage lets you balance the volume of Single
Programs to ensure that all of your Programs are of consistent volume. This is especially useful when using
Multi Programs. The Master Volume gain stage is not accessible from the top panel hardware controls, and is
controllable only over MIDI.
MOD Page
Mod Matrix
The modulation matrix provides definable modulation routes drawing from a list of Modulation Sources and
Destinations. The modulation route connects the Source to the Destination and provides a value for the
Amount of modulation. There are 16 routes available, with controls for selecting the modulation source and
destination, and for setting the amount of modulation.
Source Selects the Source (see Table 7 below) of the modulation route.
You cannot use a polyphonic source to modulate a monophonic destination. Unsupported routings are hidden by the Vyzex Ed-
itor based on the source and destination selections.
Modulation Matrix controls
Table 7. Modulation Sources
Table 8. Mod Source
MIDI Message
Env 1 NRPN01A0H–NRPN01AFH: 1
Env 2 NRPN01A0H–NRPN01AFH: 2
Env 3 NRPN01A0H–NRPN01AFH: 3
Env 1 Bipolar NRPN01A0H–NRPN01AFH: 4
Env 2 Bipolar NRPN01A0H–NRPN01AFH: 5
