M-system 60C User Manual

10. I/O SIGNALS
10.1. REMOTE I/O
The 60C occupies from 1 up to 4 nodes according to the number of I/O channels. Regardless of the number of nodes, 32 bits
are assigned to each of input and output for sending to/receiving from the Master Unit. One (1) bit among RXxB* is used as
remote device (60C) READY signal, turned ON when the 60C is in normal operation.
*. x = (Station No. × 2 – 1) H
[example] Station No. = 9
9 × 2 – 1 = 17 5 11H
READY signal is input at RX11B.
10.2. ASSIGNING REMOTE REGISTERS
1) 60C-x1
The 60C-x1 does not use the remote registers for the direction from the Master to Remote (RWwn to RWwn+15). The table
below shows the data assignment of those for the direction from the Remote to Master.
DIRECTION ADDRESS CONTENTS 60C-041 60C-081 60C-161 DEFAULT
60C
➡
Master
RWrn + 0 Ch. 1 digital output
✓ ✓ ✓
0
RWrn + 1 Ch. 2 digital output
✓ ✓ ✓
0
RWrn + 2 Ch. 3 digital output
✓ ✓ ✓
0
RWrn + 3 Ch. 4 digital output
✓ ✓ ✓
0
RWrn + 4 Ch. 5 digital output
✓ ✓
0
RWrn + 5 Ch. 6 digital output
✓ ✓
0
RWrn + 6 Ch. 7 digital output
✓ ✓
0
RWrn + 7 Ch. 8 digital output
✓ ✓
0
RWrn + 8 Ch. 9 digital output
✓
0
RWrn + 9 Ch. 10 digital output
✓
0
RWrn + 10 Ch. 11 digital output
✓
0
RWrn + 11 Ch. 12 digital output
✓
0
RWrn + 12 Ch. 13 digital output
✓
0
RWrn + 13 Ch. 14 digital output
✓
0
RWrn + 14 Ch. 15 digital output
✓
0
RWrn + 15 Ch. 16 digital output
✓
0
2) 60C-x2
The 60C-x2 does not use the remote registers for the direction from the Remote to Master (RWrn to RWrn+15). The table
below shows the data assignment of those for the direction from the Master to Remote.
DIRECTION ADDRESS CONTENTS 60C-042 60C-082 60C-162 DEFAULT
Master
➡
60C
RWwn + 0 Ch. 1 digital input
✓ ✓ ✓
0
RWwn + 1 Ch. 2 digital input
✓ ✓ ✓
0
RWwn + 2 Ch. 3 digital input
✓ ✓ ✓
0
RWwn + 3 Ch. 4 digital input
✓ ✓ ✓
0
RWwn + 4 Ch. 5 digital input
✓ ✓
0
RWwn + 5 Ch. 6 digital input
✓ ✓
0
RWwn + 6 Ch. 7 digital input
✓ ✓
0
RWwn + 7 Ch. 8 digital input
✓ ✓
0
RWwn + 8 Ch. 9 digital input
✓
0
RWwn + 9 Ch. 10 digital input
✓
0
RWwn + 10 Ch. 11 digital input
✓
0
RWwn + 11 Ch. 12 digital input
✓
0
RWwn + 12 Ch. 13 digital input
✓
0
RWwn + 13 Ch. 14 digital input
✓
0
RWwn + 14 Ch. 15 digital input
✓
0
RWwn + 15 Ch. 16 digital input
✓
0
60C
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
EM-6602 Rev.8 P. 10 / 13
