1. BEFORE USE ....
Thank you for choosing M-System. Before use, please check contents of the package you received as outlined below.
If you have any problems or questions with the product, please contact M-System’s Sales Office or representatives.
■ PACKAGE INCLUDES:
Analog I/O module (body + base socket) ....................................................................................................................................... (1)
Terminating resistor (110 Ω, 0.5 W) ............................................................................................................................................. (1)
■ MODEL NO.
Confirm Model No. marking on the product to be exactly what you ordered.
■ INSTRUCTION MANUAL
This manual describes necessary points of caution when you use this product, including installation, connection and basic
maintenance procedures.
2. GENERAL DESCRIPTION
The model 60C, Analog I/O Module, is used as remote device for CC-Link.
Model number and suffix codes are designated as follows:
60C–xx–xx
MODEL
NO. OF CHANNELS
04: 4 points
08: 8 points
16: 16 points
I/O TYPE
1: Input
2: Output
POWER INPUT
K: 85 – 132 V AC
R: 24 V DC
OPTIONS
blank: none
/Q: With options (specify the specification)
SPECIFICATIONS OF OPTION : Q
COATING (For the detail, refer to M-System’s web site.)
/C01: Silicone coating
/C02: Polyurethane coating
/C03: Rubber coating
TERMINAL SCREW MATERIAL
/S01: Stainless steel
Various inputs and outputs are available by employing 10-RACK series, 18-RACK series or other signal conditioners. The 60C
input module converts analog inputs (0 – 100%) proportionally into 16-bit signed binary signals. The one for output converts
16-bit signed binary signals proportionally into analog outputs (0 – 100%).
This instruction manual explains hardware specifications, component identification, and wiring instructions, etc.
60C
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
EM-6602 Rev.8 P. 2 / 13
