M3 Orange User Manual
Name and Function of Each Part
Power Supply
Aux. Battery Charging Slot
Main Unit Charging Slot
Cradle Charging LED
(When Charging Aux.
Battery)
USB Client:
PC Connection (Active Sync)
USB Host:
For USB host use (keyboard,
memory, etc)
USB to Serial:
USB to Serial function
(External serial connection, etc)
Cradle
Ethernet:
Enables use of Ethernet function
for Main Unit
When using Ethernet Cradle
USB Host and USB Ethernet are optional functions.•
Optional functions or items that were not purchased cannot be used.•
