Displayed Configuration (Don’t change for Hydrocontroller MASTER).
c. Press + or – to select the correct configuration for Hydrocontroller:
MASTER,SLAVE1,SLAVE2.
d. Press ENTER, and keep pressed till it will be displayed “Done.…………”.
Displayed Motor Power
a. Press + or – to change the value:
b. Set the value of electric power written on pumps label plus 10%.
c. Press ENTER, and keep pressed till it will be displayed “Done.…………”.
Displayed MAX.Motor Current
h. Press + or – to change the value
i. Insert current value as indicated on the electro-pump plate.
j. Press ENTER, and keep pressed till it will be displayed “Done.…………”.
Motor Power
Max.Motor Current
