 Displayed Sector3 pressure
d. Press + or – to change the value (from 1.00 to 7.50)
e. insert the value for irrigation sectors at the first pressure set point.
f. Press ENTER, and keep pressed till it will be displayed “Done.…………”.
 Displayed Sector4 pressure
d. Press + or – to change the value (from 1.00 to 7.50)
e. insert the value for irrigation sectors at the first pressure set point.
f. Press ENTER, and keep pressed till it will be displayed “Done.…………”.
Sector4 Pressure
3
,
00
Bar
Sector3 Pressure
2
,50 Bar
Sector2 Pressure
2
,
0
0 Bar
