4. HC PROGRAMMING
4.1. Factory settings
Service pressure (Ps) 2,5 Bar
Re-starting pressure (Pr) 2 Bar
Max. electro-pump current 0,45 A
Number of pumps 1
HC condition at power on off
Configuration 0
4.2. Start up procedure
IMPORTANT
On initial starting up it is essential:
HCMT HCMM
To check the correct electro-pump rotation
direction
To set the current as indicated on the
electro-pump plate for triangle connection
If necessary modify the service pressure
Not modify “Configuration” parameter
To set the current as indicated on the
electro-pump plate
If necessary modify the service pressure
Not modify “Configuration” parameter
Parameter that may be modified with the starting up procedure
Parameter Description
Language Selection of the language in which the messages are
written on the display
Maximum current settings Is the maximum current that may be absorbed with the
engine running. Should this value exceed 10% for 1
minute continually, HC goes into a protection mode.
It is a number of between
HCMT: 0.45 and 8.50 (expressed in A rms).
HCMM: 0.45 and 10 (expressed in A rms
Garden Mode If it is ON it is possibile to set 4 different pressare-sets,
using the device MULTIPRESS4.
If it is OFF it is available only the system pressure set.
Pressure SetPoint 1 Set the desired pressure for the setpoint 1. It’s a number
between 1.00 and 7.50 (is expressed in Bar).
It is available only in Garden Mode ON
Pressure SetPoint 2
Set the desired pressure for the setpoint 2. It’s a number
between 1.00 and 7.50 (is expressed in Bar).
It is available only in Garden Mode ON
Pressure SetPoint 3 Set the desired pressure for the setpoint 3. It’s a number
between 1.00 and 7.50 (is expressed in Bar).
It is available only in Garden Mode ON
Pressure SetPoint 4 Set the desired pressure for the setpoint 4. It’s a number
between 1.00 and 7.50 (is expressed in Bar).
It is available only in Garden Mode ON
ON/OFF Sezione 1.02 ON start autoclave: the electro pump is
piloted to maintain stable the pressure.
OFF the electro pump is always switch off.
(*) changeable only in XP configuration
