Start up procedure for HC MM 1P/HC MT 1P
Start up procedure Actions
Power the device HC. After the visualization of Hydrocontroller
model and software version it will be displayed:
Installation (+)
Start (ENTER)
Press+ and then it passes automatically to:
Press + to start the procedure of installation.
Press ENTER to start the system without doing
installation.
Language
English
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the language
Max.Motor Current
0.450 Ampere
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
(for MT model from 0.450 to 8.500 ampere).
(fot MM model from 0.450 to 10.000 ampere)
Insert current value as indicated on the
electro-pump plate.
Garden Mode
OFF
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
ON: active Garden Mode
OFF: deactive Garden mode
If Garden Mode = ON
it passes automatically to:
Sector1 Pressure
1.50 Bar
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
(from 1.00 to 7.50)
insert the value for irrigation sectors at the
first pressure set point.
Sector2 Pressure
2.00 Bar
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
(from 1.00 to 7.50)
insert the value for irrigation sectors at the
second pressure set point.
Sector3 Pressure
2.50 Bar
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
(from 1.00 to 7.50)
insert the value for irrigation sectors at the
third pressure set point.
Sector4 Pressure
3.00 Bar
Pressing ENTER, the value is saved in memory.
Keep pressed ENTER till it will be displayed “Done.…………”
and then it passes automatically to:
Press + or – to change the value
(from 1.00 to 7.50)
insert the value for irrigation sectors at the
fourth pressure set point.
If Garden Mode = OFF
it passes automatically to:
System Pressure
4.00 Bar
Press + or – to change the value
(from 1.00 to 7.50)
insert the value for desired pressure of the
system.
