MACES4C-00 Operator UI manual 17
For Macas coffee machine menu system, one menu icon could response up to 4 products, defined by a
diamond product tree. Please refer to IPD designer user manual 4.4.2 Product Tree for further
information.
Color bars to the left is to display the product tree. It can be up to 4 products of the tree. Each row is on
product, and has different color.
Color scroll bars to the right are recipe adjustment area. Each ingredient can be adjusted to +/- 50% in a
relative way.
To adjust water will keep the taste of the product, so the absolute value of other ingredient will change
automatically. But the relative values of other ingredients are unchanged.
To adjust ingredients other than water, the product taste will change. For instance, to add more sugar to
this product will make it sweeter.
The “Factory Default” button on the bottom can clear all customized changes.
4.2.3 Edit price
Press the “Edit price” tab, will so the screen like below. Only the lower part is different.
