Mackie SRM-Flex - SRM-Flex System Features; Powerful SRM Sound; Wireless Control with SRM-Flex Connect; Integrated 6-Channel Digital Mixer

Owner’s Manual
3
Owner’s Manual
Contents Features
Part No. SW277 Rev. A 09/9
©2019 LOUD Audio, LLC. All Rights Reserved.
• Lightweight, Small Footprint, Built-Like-A-Tank
o Lightweight all-in-one design oers everything
you need for your gig
o Load in to your next gig and be set up in minutes
o Fits just about anywhere and disappears in any room
o Rugged design is built to last
• Proven SRM Sound with Ultra-Wide Coverage
o 300W of power delivers maximum headroom
and top performance
o 6-driver wide-dispersion array and 0" subwoofer
provide crystal-clear, room-filling sound
o Adjustable height directs the sound at ear level
for optimal coverage and clarity
o For audiences of up to 00 people
• Complete Wireless Control with SRM-Flex Connect™
o Pair your smartphone and get wireless control over
everything from channel levels to EQ, system presets,
and more
o Mount your phone to your mic stand for on the fly
adjustments or have a dedicated engineer mix you
from the audience
o Compatible with iOS and Android® devices*
• Stream Your Music
o Need to play some break music or a backing track?
No need to worry about the cable. Stream music straight
from your phone or any Bluetooth® enabled device.
• Built-in 6-Channel Digital Mixer
o The built-in 6-channel digital mixer has inputs for mics,
instruments, and media players
o Professional XLR out allows for connection
to an additional SRM-Flex or front-of-house mixer
• Dial in Your Sound
o 2-Band EQ on channels  and 2 allow you to easily adjust
the tone of your mic, guitar, keyboard, or anything else
you plug in to get the sound just right
o Application voicing modes tailor the system to your
application and venue. Choose between Music, Speech,
and Live.
• Find the Perfect Reverb
o Put the finishing touch on your sound with a choice
of not just , but 3 great-sounding reverbs
• Zero-Fuss Physical Controls
o With tactile knobs for every critical function
and adjustment, you can get to what you need without
the hassle of navigating menus on a small screen
• Weight and Dimensions (H x W x D)
o 29.6 lb. / 3.4 kg
o 7.0 x 3.0 x 4.2 in / 432 x 330 x 36 mm (Base only)
o 79.0 x 2.8 x 3.0 in / 2007 x 7 x 76 mm
(Total size with extenders)
• Included Accessories
o Carry bag for array module and extenders
o Protective cover for subwoofer/mixer module
*SRM-Flex Connect requires iOS  or later or Android 6 or later
Like us
Follow us
Watch our dang videos
Important Safety Instructions ........................................... 2
Contents / Features ............................................................ 3
Introduction / Getting Started ........................................... 4
Hookup Diagrams ............................................................... 5
Base Station ........................................................................ 9
SRM-Flex Connect™ App ................................................... 9
SRM-Flex: Rear Panel Features ......................................... 9
. Power Connection ....................................................9
2. Power Switch ...........................................................9
SRM-Flex: Top Panel Features ..........................................0
3. Power LED ...............................................................0
4. XLR and /4" Combo Inputs [Chs.  and 2] ...........0
5. Line / Hi-Z Switches [Chs.  and 2] ....................... 
6. /4" Stereo Line Inputs [Ch. 3/4] .......................... 
7. Sig / OL LEDs ........................................................... 
8. /8" Stereo Line Input [Ch. 5/6] ........................... 
9. Bluetooth Button [Ch. 5/6] ................................... 
0. Volume Knobs .......................................................2
. Reverb Send Knobs [Chs.  and 2] .......................2
2 and 3. Low and Hi EQ Knobs [Chs.  and 2] .......2
4. Reverb Button .......................................................3
5. Speaker Mode Button...........................................3
6. Super Power Button .............................................3
7. Master Volume Knob .............................................4
8. Main Meters .......................................................... 4
9. Limiter LED ...........................................................4
20. Mix Out .................................................................4
Protection Circuitry ...........................................................5
Limiting .......................................................................5
Overexcursion Protection ..........................................5
Thermal Protection ....................................................5
AC Power ............................................................................5
Care and Maintenance ......................................................5
Placement ..........................................................................6
Appendix A: Service Information ...................................... 7
Appendix B: Technical Information ..................................8
SRM-Flex Dimensions ................................................9
SRM-Flex Block Diagram .......................................... 20
Limited Warranty ...............................................................2
