Mackie Thump12BST - Loudspeakers Block Diagram

Thump12BST • Thump15BST Powered Loudspeakers
28
Thump12BST • Thump15BST Powered Loudspeakers
Thump12BST / Thump15BST
Loudspeakers Block Diagram
HF LF
Amp Amp
Limiter Limiter
Mute Mute
LF
Equalization
HF
Equalization
Thermal Monitoring
Crossover
3x1 mixer with user controlled input gains
6 user
selectable
voicings
Master
Gain
User
EQ
User
EQ
Digitally-
controlled
Preamp
Digitally-
controlled
Preamp
User
EQ
