Mackie Thump15BST - Daisy-Chaining Multiple Speakers

Thump12BST • Thump15BST Powered Loudspeakers
8
Thump12BST • Thump15BST Powered Loudspeakers
Daisy-Chaining Multiple Thump Loudspeakers
Hookup Diagrams continued...
1402VLZ4 Mixer
To next
Thump
loudspeaker
input
To next
Thump
loudspeaker
input
Main
Outs
To next
Thump
loudspeaker
input
Thump loudspeakers may be daisy-chained via the male XLR connector labeled “MIX OUT”.
Simply plug the signal source (i.e., mixer output or microphone) into the input jack(s), and patch
that loudspeaker’s mix out jack to the next loudspeaker’s input jack, and so on, daisy-chaining
multiple Thump loudspeakers. See above for visual representations of daisy-chaining.
