Thump212XT and Thump215XT 1400W Enhanced Powered Loudspeaker Series
22
Thump212XT and Thump215XT 1400W Enhanced Powered Loudspeaker Series
ThumpXT Block Diagram
Amp
Amp
Limiter
Limiter
LF
Equalization
HF
Equalization
Thermal
Monitoring
Crossover
2-channel
mixer with
user-controlled
input gains
(app only)
2-band
User EQ
(app only)
Level and Mute
Controls
(app only)
MUSIC
MON
LIVE
CLUB
SUM
1/8" / 3.5mm
