2016
Diamond Series
The third generation HVLS(Super High Volume-Low Speed) large energy-saving ceiling fan named by is an
application based on permanent-magnet brushless tech, acme industry design and intelligent control tech.
The fans can circulate the airlfow in the space efficiently, then improve the comfortable feeling greatly. The product
combined a series of advanced technologies, such as aerodynamics, industry design, dynamics, pulse width
modulation(PWM) control technology, mechanics, computer software, simulation technology.
The product is widely used in commercial space, industrial space, stadiums, airports, office space, auditorium, restaurant
and other large & high occasions.
1.1 Product specification table
-3-
1. Production series introduction
INSTALLATION GUIDE
Note:
1, Weight: the weight does'nt contain control box, top connection parts et c.
2, Size: the above-mentioned product size is standard, other size c an be customized.
3, Noise: sound level measured a distance of 1 m from the motor, electromagnetic noise is less than 40 db(A).
4, Packing: Carton packing.
5, Input power : 220V/1PH
Model HVLS- 24 HVLS-30 HVLS- 36 HVLS- 42
Diameter 2.4m (8ft) 3.0m (10ft) 3.6m (12ft) 4.2m (14ft)
Max Speed 120RPM 100RPM 90RPM 76RPM
Max Power 150W 300W 405W 410W
Max Air Volume 1490CMM 2380CMM 3010CMM 3730CMM
Input Voltage 220V 220V 220V 220V
Max Current 2.0A 2.0A 2.0A 2.0A
Noise Level 41dBA 40dBA 39dBA 39dBA
