MacroAir Technologies Diamond HVLS Series - Standard Components Introduction

5 Main body structure3 Steel structure fastening
Control system structure
-5-
2.1 Standard components introduction
INSTALLATION GUIDE
2016
fasteners
H-beam
shim
clamp plate
top plate
control cabinet
switch
speed controller
stator shaft
upper dust cover
rotor
bottom cover
