-4-
2. Product drawing
INSTALLATION GUIDE
1. H-type steel structure 6. Separating connector
2. Clamp plate 7. Steel wire
3. Extension tube 8. L-type adapting pieces
4. Turnbuckle and clamps 9. Fan blade
5. BLDC motor 10. Fan blade tail
1
2
3
4
5
6
7
8
9
10
