Macrom M2A.2000 User Manual

Front/Rear view
Low Level Input
High Level Input
Gain Controll
High pass switch
High pass cutting adjustment
Multiplayer x1/x10 switch
Steroe Mono input selector
Low pass switch
Low pass cutting adjustment
Multiplayer x1/x10 switch
Led indicator
Fuse
12V (DC) power terminal
Remote terminal
GND terminal
+ Left channel terminal (+ MONO)
- Left channel terminal
+ Rigth channel terminal
- Rigth channel terminal (- MONO)
