Madimack ELITE V3 - Dimension

10
7. Dimension
※ Above data is subject to modification without notice.
Note: Above swimming pool heat pump specification drawing is for installation reference only to
technical staff.
A
B
C
D
E
F
G
H
ESV3-110
510
450
504
530
749
300
75
656
ESV3-140
510
450
504
530
749
280
75
656
ESV3-170
510
540
504
530
839
350
75
656
ESV3-220
510
680
504
530
979
460
75
756
ESV3-270
520
760
514
540
1132
460
75
756
ESV3-320
ESV3-400
Name
Size(mm)
Model
