17
1. Installation reminder
Only competent persons are authorized to install the heat pump and should be educated with the
relevant building codes and standards of their current state or local governing body for all
electrical, mechanical and water services to prevent danger or damage to the unit.
a. Location and clearances
The inverter pool heat pump should be installed in a good ventilation place.;
b. Typical installation diagram
Installations can differ dependent on-site conditions below is only a representation of one
possibility.
Note: the inlet and outlet positions for the pipework is a representation only and can be positioned
differently.
Please see section: Installation options for more information of accessories available and
different plumbing layouts
water outlet
valve
water
return
Chlorinator cell
(or other treatment)
water inlet
valve
By-pass
valve
Filtration
pump
Filter
Pool
