Specifications
Inclination Angle
110°, min.
(98°, min. to plus range and 12°, min. to minus range, based on 0°of the chart above.)
Total Accuracy ±1% under vibrating conditions (Including linearity and hysteresis).
Response
Approx. 1 second at Inclination angle 90°
(Adequate under operation temperature conditions)
Potentiometer (CP-2 or equivalent)
Significant Electrical Angle 340° +2°/-3°
Total Resistance 1 k-ohm ± 20%
Index Point Output to calibrate to 15±3% at the condition of above chart (0°)
Insulation Resistance 200 M-ohm, minimum, DC 500 V
Withstand Voltage AC500V, 1 minute
Rated Current 0.5W/50°C
Resistance to Environment
Operation Temperature Range -30 to 80°C
Stand-by Temperature Range -40 to 80°C
Vibration Resistance
50m/S
䋲
33Hz Each 2 hours to 3 axises
Resistance to Impact
200m/S
䋲
Each 3 impacts for 6 directions
Protection Classification IP64
Damper Oil, used
Silicon Oil 500mm
䋲
/s (Toshiba Silicon TSF451-500 )
