8. INPUT/OUTPUT
8.1 CONVERTER
Direction Description Q’ty Specifications
Pressure Sensor 1 1
Analog input [1 to 2.4V / 0 to 20.6 MPa (0 to 210kgf/cm
䋲
)]
Pressure Sensor 2
1
Analog input [1 to 2.4V / 0 to 20.6 MPa (0 to 210kgf/cm
䋲
)]
Length Sensor
1
Analog input (0.72 to 3.07V / 0 to 4.5m)
Angle Sensor
1
Analog input (1.8 to 2.8V / 0 to 80°)
Boom Angle Upper Limit
1
Photo Coupler input (See Note 1)
Boom Angle Lower Limit
1 Photo Coupler input (See Note 1)
Over Hoist Detector
1 Photo Coupler input (See Note 1)
Input
Over Un-Winding Detector
1 Photo Coupler input (See Note 1)
Output Serial Communication
1
Data from each Sensors and Switches
Note 1: Photo Coupler input




