Maeda MC285C-2 - Rated Total Load Chart for 4 Falls

RATED TOTAL LOAD CHART FOR 2 FALLS
OUTRIGGER EXTENDED TO MAXIMUM
2.535m/4.075m BOOM
5.575m BOOM 7.075m BOOM 8.575m BOOM
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
1.4 or less 1410 3.0 or less 1220 3.6 or less 820 4.0 or less 550
1.50 1410 3.50 970 4.00 740 4.50 400
2.00 1410 4.00 780 4.50 580 5.00 340
2.50 1410 4.50 630 5.00 480 5.50 300
3.00 1220 5.00 530 5.50 430 6.00 270
3.50 970 5.205 530 6.00 380 6.50 230
3.705 920 -- -- 6.50 350 7.00 200
-- -- -- -- 6.705 330 7.50 180
-- -- -- -- -- -- 8.00 150
-- -- -- -- -- -- 8.205 150
OUTRIGGER EXTENDED TO OTHER THAN MAXIMUM
2.535m/4.075m BOOM
5.575m BOOM 7.075m BOOM 8.575m BOOM
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
Working
radius (m)
Rated total
load (kg)
1.5 or less 1410 3.0 or less 510 3.6 or less 400 4.0 or less 330
2.00 1070 3.50 410 4.00 330 4.50 280
2.50 630 4.00 330 4.50 280 5.00 230
3.00 520 4.50 280 5.00 230 5.50 180
3.50 390 5.00 200 5.50 180 6.00 160
3.705 350 5.205 200 6.00 160 6.50 130
-- -- -- -- 6.50 130 7.00 100
-- -- -- -- 6.705 120 7.50 80
-- -- -- -- -- -- 8.00 70
-- -- -- -- -- -- 8.205 60
The Rated total load Chart is based on actual working radius with the bending of boom attributable to
load reflected and is shown with the mass of hook block (30kg) included.
