12
USING THE GRATING/SLICING DISCS
We recommend that you use the discs in the Midi bowl.
Slide the extension over the motor shaft.
For non-reversible discs, make sure you
place the disc the right way up.
Place the chosen disc with the relevant
reference facing upwards.
Slide the disc onto the extension. Turn it so
that it slots on properly. This is a two-stage
process.
• Always handle the discs with care, as
the blades are extremely sharp.
• Never insert your fingers or a foreign
object into the feed tube. Always use
the pusher designed for that purpose.
W A R N I N G
Slicing/grating disc : each side is engraved
with a reference code, e.g. R/G4 = 4-mm
grater, E/S 2 = 2-mm slicer.
For all XL Food Processors discs are non-reversible.
R
/
G
4
E
/
S
2
1 2
3 4
R
/
G
4
