ExpressBox 3T | Chapter 2 Hardware Installation
Extra Power
Some PCIe cards require extra power. There are two 4 pin AUX power connectors that can be used for providing
extra power to cards.
If you need to add another 4 pin AUX tab you can connect an AUX Y splitter
IMPORTANT
Y cable is only shipped / included with First generation (pre production ) of EB3T expansion units
that have one Auxiliary Power cable. This is applicable to EB3T Units with Date Code
MG211A111XXXX.
Second batch of EB3T expansion units with Date Code MG211A1202 (and above) have
already 2 Auxiliary power cables (built-in). These are two 4pin Male molex connectors.
: The
Y Splitter is no longer included with these units
.
