ExpressBox 3T | Chapter 3 Verify Installation
33
IMPORTANT
If there is no Display Monitor attached to Thunderbolt™ 1 Interface card it would only show 4
illuminated solid GREEN LEDs, this is normal.
See picture below.
.
FIGURE T1-B
IMPORTANT
LEDs D700 and D701 on the Thunderbolt™ 1 Interface card are illuminated when power cord is
attached to expansion unit. This means the expansion unit is on standby-mode.
See picture below.
FIGURE T1-C
