1-14-1 T8100PIN
IC PIN FUNCTIONS
IC1201 (TV Micro Controller)
Pin
No.
Signal Name Function
1GND GND
2 N.U. Not Used
3 N.U. Not Used
4 TEST1 TEST 1
5GND GND
6VCC AL+5V
7 TEST 0 TEST 0
8 FILT FILT
9 HLF Filter for CCD
10 VHOLD VHOLD
11 CVIN Input for Video Signal
12 RESET RESET
13 N.U. Not Used
14
VIDEO LINE
OUT
Composite Signal Output
15 GND GND
16 3.58 X'TAL 3.58MHz Crystal
17 C-APC CHROMINANCE APC
18 5.7V REG OUT 5.7V Output
19 AUX2(R)IN AUX Audio R Input
20 N.U. Not Used
21 AUX2(L)IN AUX Audio L Input
22 VCC VCC
23 N.U. Not Used
24 CVBS IN2
Composite Signal Input 2
(LINE)
25 AUX1(L)IN DVD Audio L Input
26 CVBS IN1
Composite Signal Input 1
(TUNER)
27 AU MONO IN Audio Input (TUNER)
28 5.7V REG OUT 5.7V Output
29 C IN DVD Chrominance Signal
30 Y IN DVD Luminance Signal
31 V REG VCC DC 8.7V Input
32 FSC OUT Clock Output 3.58MHz
33 N.U. Not Used
34
AUDIO ATT
OUT(L)
Audio Output L
35
AUDIO ATT
FILTER
Audio Filter
36 AUX1(R)IN DVD Audio Input R
37 V RAMP F/B V Ramp Feed Back
38 V RAMP OUT Vertical Output
39 V RAMP CAP V Ramp OSC Capacitor
40 8.7V REG OUT 8.7V Output
41
AUDIO ATT
OUT(R)
Audio Output R
42 H VCO F/B H Vco Feed Back
43 AFC FILT Horizontal AFC Filter
44 GND GND
45 FBP IN Flyback Pulse Input
46 H-OUT H Pulse Output
47 VCC Vcc
48 VCC Vcc
49 VCC Vcc
50 R OUT Red Output
51 G OUT Green Output
52 B OUT Blue Output
53 ACL IB-Input
54 N.U. Not Used
55 DVD-L DVD at Low
56 SDA
I2C-BUS Controller Interface
(Data)
57 I2C-OPEN
White Balance Adjustment
Judgement
58 SCL
I2C-BUS Controller Interface
(Clock)
59 CS DVD Interface Chip Select
60 SDATA DVD Interface Data
61 SCLK DVD Interface Clock
62 VOLUME Volume Control
63 AMP-STANDBY
Speaker Amp. ON/OFF
Output Signal
64 REMOTE-OUT
DVD Control Key Code
Output
Pin
No.
Signal Name Function
