1-14-2 T8100PIN
65
DVD-AUDIO-
MUTE
DVD Mute Signal Input
66 KEY-0 Key Input 0
67 KEY-1 Key Input 1
68 N.U. Not Used
69 AFT AFT Voltage Input
70 REMOTE Input for Remote Control
71 N.U. Not Used
72 SPOT-KILL Spot Countermeasure
73 P-SAFETY 1 Power Supply Protection
74 P-SAFETY 2 Power Supply Protection
75 P-SAFETY 3 Power Supply Protection
76 N.U. Not Used
77
DVD-MAIN-
POWER
Power On Signal to High for
DVD
78 P-ON-H Output for P-ON-H
79 SP-MUTE Audio Mute Signal
80 ACL-CONT ACL Control Signal
Pin
No.
Signal Name Function
