Magnavox MWC24T5 Service Manual

WIRING DIAGRAM < TV/VCR Section >
T2202WIT
1-13-1
1 2
CRT CBA
FOCUS
SCREEN
GND
L551 D.Y.
HD VD
CL2501A CL2501B
MAIN CBA
SUB CBA
CN2501
W1601
CN1601
1 2
3 4
5
T2571 FBT
CL2504A
ANODE
CN2571
FULL ERASE HEAD
CL1403
FE HEAD
AUDIO HEAD CONTROL HEAD
ACE HEAD ASSEMBLY
AUDIO ERASE HEAD
M
LOADING MOTOR
CYLINDER ASSEMBLY
1
CM+12V
P-ON+5V(3)
2 3
C-FG
CM-F/R
4
C-CONT
5
FG-GND
6
LD-CONT
7
D-CONT
8
D-PFG
9
M-GND
10
D/L+12V
11
VG+15V
12
CL1201 CL1401
CN1602 CN2502 CN2
CN1
CAPSTAN MOTOR
Hi-Fi- AUDIO(L) HEAD Hi-Fi- AUDIO(R) HEAD VIDEO (R)-2 HEAD VIDEO (L)-2 HEAD VIDEO (L)-1 HEAD VIDEO (R)-1 HEAD
CL1402
TO CN1A TO CN2A
Hi-Fi-AUDIO(L)
9
Hi-Fi-COM
8
Hi-Fi-AUDIO(R)
7
VIDEO(R)-2
6
VIDEO-COM2
5
VIDEO(L)-2
4
VIDEO(L)-1
3
VIDEO-COM1
2
VIDEO(R)-1
1
AE-H
6
AE-H/FE-H
5
AUDIO-COM
4
AUDIO-PB/REC
3
CTL(+)
2
CTL(-)
1
FE-H
1
FE-H-GND
2
P-ON+8V(1)
1
RED
2
GREEN
3
BLUE
4
HEATER
11
GND
22
+180V
33
FUNCTION CBA
CN2401CN1803
SP(L)
11
GND
22
SP(L)
33
NU
44
KEY1
55
NU
66
GND
77
DVD-AUDIO-MUTE
9
DVD-Y
8
GND
7
DVD-C
6
GND
5
DVD-AUDIO(L)
4
DVD-AUDIO(R)
3
GND
2
SPDIF
1
EV+1.2V
1
EV+1.2V
2
EV+1.2V
3
GND
4
GND
5
GND
6
GND
7
GND
8
PWRCON
15
EV+3.3V
9
EV+3.3V
10
DVD-ON+3.3V
11
DVD-ON+5V
12
EV+9V
14
EV+9V
13
GND
5
11+B 22+B 33GND 44GND 55GND 66+26V 77GND 88GND 99GND
10 10EV+4V 11 11EV+4V 12 12GND 13 13GND 14 14DVD-ON+9V 15 15GND 16 16P-ON+5V(4) 17 17P-SAFETY1 18 18P-SAFETY2 19 19DVD-REMOTE
CN1301 CN2503
11H-DRIVE 22ACL 33RED 44GREEN 55BLUE 66P-ON+8V(1) 99V-RAMP-NF 77AFC 88V-DRIVE
10 10DVD-Y 11 11DVD-C 12 12P-SAFETY3 13 13SDATA 14 14
SCLK
15 15
CS
16 16
DVD-AUDIO-MUTE
17 17
DVD-MAIN-POWER
18 18
DVD-AUDIO(L)
19 19
DVD-AUDIO(R)
SENSOR CBA (ST-SENSOR) SENSOR CBA (END-SENSOR)
M
DRUM MOTOR
PG SENSOR
CONTINUE WIRING DIAGRAM <DVD SECTION>
WIRING DIAGRAM FOR DECK MECHANISM SECTION
JUNCTION-A CBA
SP1801 SPEAKER R-CH
SP-GND
1SP(R) 2
CL3802
CN3802CN1802
SP(R)
11
SP(R)
22
SP-GND
33
SP-GND
44
JUNCTION-B CBA
SP801 SPEAKER L-CH
SP-GND
1SP(L) 2
CL3801
CN3801CN2801
SP(L)
11
SP(L)
22
SP-GND
33
SP-GND
44
DVD-ON+5V(NU)
10
DVD-REMOTE
19
SCLK
16
S DATA
18
CS
17
1 2 3 4 5
CL2601
