Magnavox MWC24T5 Service Manual

T2202WID
1-13-2
WIRING DIAGRAM < DVD Section >
DVD MAIN CBA UNIT
CONTINUE WIRING DIAGRAM <TV/VCR SECTION>
TO CN1
CN301
6 5
GND SL(-) SL(+)
4 3
SP(-)
2
SP(+)
1 TRAY-IN
TRAY-IN
DRIVE CBA
M
SLED MOTOR
M
SPINDLE MOTOR
EV+1.2V
EV+1.2V EV+1.2V
GND
GND
GND
GND
1 2 3 4 5 6 7
GND
PWRCON
EV+3.3V
8
15
9
10 11 12
CN1A
PICK UP UNIT
CN201
1 2 3 4 5 6 7 8 9
10 11 12 13 14 15 16 17 18 19 20
TS(+) TS(-) FS(-) CD-LD FS(+) GND(DVD-PD) GND(CD-PD) PD-MONI DVD-LD VREF NU GND B P-ON+5V CD/DVD D A C NU GND(LD)
DETECTOR
FSTS
7 9
11
2 3 6 5 4
TO CN2
SPDIF
GND
DVD-AUDIO(R)
DVD-AUDIO(L)
GND
1 2 3 4 5
CN2A
DVD-C
DVD-Y
GND
DVD-AUDIO-MUTE
6 7 8 9
EV+3.3V
DVD-ON+3.3V
DVD-ON+5V
EV+9V
14 13
EV+9V
DVD MECHANISM
DVD-ON+5V(NU)
10 16 17
SCLK
CS
S DATA
19 18
DVD-REMOTE
