1-14-1 X7T4HTI

SYSTEM CONTROL TIMING CHARTS

< TV/VCR Section >

Mode SW: LD-SW

Note: EJ RS: Loading FWD (LM-FWD / REV “H”)

RS EJ: Loading REV (LM-FWD / REV “L”)

Stop (A) = Loading

Stop (B) = Unloading

Note:

LD-SW Position detection

A/D Input voltage Limit

(Calculated voltage)

Symbol

3.76 V ~ 4.50 V (4.12 V) EJ

4.51 V ~ 5.00 V (5.00 V) CL

0.00 V ~ 0.25 V (0.00 V) SB

1.06 V ~ 1.50 V (1.21 V) TL

0.66 V ~ 1.05 V (0.91 V) FB

1.99 V ~ 2.60 V (2.17 V) SF

1.51 V ~ 1.98 V (1.80 V) SM

3.20 V ~ 3.75 V (3.40 V) AU

0.26 V ~ 0.65 V (0.44 V) AL

4.51 V ~ 5.00 V (5.00 V) SS

2.61 V ~ 3.19 V (2.97 V) RS

Note:

Symbol Loading Status

EJ Eject

CL Eject ~ REW Reel

SB REW Reel ~ Stop (B)

TL Stop (B) ~ Brake Cancel

FB Brake Cancel ~ FF / REW

SF FF / REW ~ Stop (M), (FF / REW)

SM Stop (M), (FF / REW) ~ Stop (A)

AU Stop (A) ~ Play / REC

AL Play / REC ~ Still / Slow

SS Still / Slow ~ RS (REW Search)

RS RS (REW Search)
