Magnavox MWC24T5 Service Manual

20060325 1-19-2 T2202EL
C1428 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1429 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C1430 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1431 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1432 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C1435 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C1436 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1437 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1438 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1439 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1441 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1442 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1443 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1444 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1445 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1452 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1463 CHIP CERAMIC CAP. CH J 820pF/25V CHD1EJ3CH821
C1464 CHIP CERAMIC CAP.(1608) B K 2700pF/50V CHD1JK30B272
C1465 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1466 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1468 ELECTROLYTIC CAP. 33µF/16V M H7 CE1CMAVSL330
C1469 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1604# METALIZED FILM CAP. 0.22µF/250V CT2E224MS037
C1605# METALIZED FILM CAP. 0.22µF/250V CT2E224MS037
C1606 CERAMIC CAP. F Z 0.01µF/500V CCD2JZP0F103
C1607 CERAMIC CAP. F Z 0.01µF/500V CCD2JZP0F103
C1610 ELECTROLYTIC CAP. 470µF/200V LX CA2D471S6017
C1611 CERAMIC CAP. BN 820pF/2KV CCD3DKA0B821
C1612 FILM CAP.(P) 0.047µF/50V J CMA1JJS00473
C1613 FILM CAP.(P) 0.0018µF/50V J CMA1JJS00182
C1614 FILM CAP.(P) 0.1µF/50V J CMA1JJS00104
C1615 CERAMIC CAP. BN 680pF/2KV CCD3DKA0B681
C1616 ELECTROLYTIC CAP. 100µF/160V M CE2CMZPDL101
C1617 ELECTROLYTIC CAP. 470µF/35V M CE1GMASDL471
C1618# ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPDL102
C1619 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1620 ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPDL102
C1622 FILM CAP.(P) 0.0047µF/50V J CMA1JJS00472
C1625 ELECTROLYTIC CAP. 0.47µF/50V M H7 CE1JMAVSLR47
C1626# ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C1627 ELECTROLYTIC CAP. 1000µF/16V M CE1CMZPDL102
C1630# SAFETY CAP. 4700pF/250V KX CA2E472MR050
C1642 CHIP CERAMIC CAP.(1608) B K 1000pF/50V CHD1JK30B102
C1643 ELECTROLYTIC CAP. 2200µF/6.3V CE0KMASDL222
C1661 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C1683 ELECTROLYTIC CAP. 220µF/6.3V M H7 CE0KMAVSL221
C1688# ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1689 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C1691 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1740 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C1747 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1748 CHIP CERAMIC CAP.(1608) B K 0.022µF/50V CHD1JK30B223
C1752 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1753 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMAVSL100
C1754 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1755 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1756 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMAVSL100
C1757 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1758 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1759 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1760 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C1762 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1763 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
Ref. No. Description Part No.
C1764 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMAVSL101
C1766 ELECTROLYTIC CAP. 2.2µF/50V M H7 CE1JMAVSL2R2
C1769 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1770 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C1771 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1772 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1773 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMAVSL100
C1774 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1775 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1776 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1777 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1778 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C1779 ELECTROLYTIC CAP. 2.2µF/50V M H7 CE1JMAVSL2R2
C1780 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1781 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1782 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1783 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1784 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C1786 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1787 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1788 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1789 ELECTROLYTIC CAP. 22µF/16V M H7 CE1CMAVSL220
C1790 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1791 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1792 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C1793 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1794 ELECTROLYTIC CAP. 10µF/25V M H7 CE1EMAVSL100
C1795 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1796 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C1797 ELECTROLYTIC CAP. 100µF/10V M H7 CE1AMAVSL101
C1801 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1807 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1810 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1811 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1812 CHIP CERAMIC CAP. B K 1500pF/50V CHD1JK30B152
C1813 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1814 ELECTROLYTIC CAP. 2.2µF/50V M H7 CE1JMAVSL2R2
C1815 ELECTROLYTIC CAP. 47µF/25V M H7 CE1EMAVSL470
C1816 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C1818 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1819 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C1821 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1822 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1870 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C1871 ELECTROLYTIC CAP. 100µF/16V M H7 CE1CMAVSL101
C1872 CERAMIC CAP. B K 470pF/100V CCD2AKS0B471
C1873 FILM CAP.(P) 0.018µF/100V J CMA2AJS00183
CONNECTORS
CN601A TERMINAL PRINTBORD PIN MS-PIN155155 JTEA001CHY01
CN601B TERMINAL PRINTBORD PIN MS-PIN155155 JTEA001CHY01
CN1301 BOARD CONNECTOR 19P(PB FREE)
127301119K2
JCTWA19TG004
CN1602 BOARD CONNECTOR 19P(PB FREE)
127301119K2
JCTWA19TG004
CN1802 242 SERIES CONNECTOR 224202104W1 J322C04TG001
CN1803 TWG CONNECTOR 07P TWG-P07P-A1 J3TWA07TG001
DIODES
D1032 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1204 LED LTL-4214M1 NPQZLTL4214M
D1211 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1215 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D1216 LED LAMP 333GT/F45-50 NPWZ3GTF4550
D1217 LED LTL-4214M1 NPQZLTL4214M
Ref. No. Description Part No.

Magnavox MWC24T5 Specifications

General

Brand	Magnavox
Model	MWC24T5
Category	TV DVD Combo
Language	English
