Magnavox MWC24T5 Service Manual

20060325 1-19-6 T2202EL
SENSOR CBA
MPS CBA
SUB CBA
TL6 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
TP1202 PCB JUMPER D0.6-P16.0 JW16.0T
TP1301 PCB JUMPER D0.6-P9.0 JW9.0T
TP1302 PCB JUMPER D0.6-P8.0 JW8.0T
TP1303 PCB JUMPER D0.6-P8.5 JW8.5T
TP1304 PCB JUMPER D0.6-P5.0 JW5.0T
TP1305 PCB JUMPER D0.6-P5.0 JW5.0T
TP1306 PCB JUMPER D0.6-P11.5 JW11.5T
TP1401 PCB JUMPER D0.6-P13.5 JW13.5T
TP1402 PCB JUMPER D0.6-P17.5 JW17.5T
TP1403 PCB JUMPER D0.6-P23.0 JW23.0T
TP1701 PCB JUMPER D0.6-P22.5 JW22.5T
TP1702 PCB JUMPER D0.6-P26.0 JW26.0T
TP1703 PCB JUMPER D0.6-P29.0 JW29.0T
TU1001 TUNER UNIT TEFH9-001A UTUNNTUAL042
VR1601# CARBON P.O.T. VZ067TL1 B103 PB(F) VRCB103HH014
W1601# AC CORD (PB FREE) A0A0280-012 WAC0172LTE12
WT1 LEAD CLAMPER 1790256
X1201 XTAL DT38 32.768kHz FX0323LDS001
X1202 XTAL HC-49/U 10.6MHz FXD106LLN001
X1301 XTAL 3.579545 MHz FXD355LLN003
X1401 XTAL 3.579545MHz(20PPM) FXC355LLN004
Ref. No. Description Part No.
SENSOR CBA
Consists of the following:
1ESA12193
TRANSISTORS
Q1201 PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Q1202 PHOTO TRANSISTOR MID-32A22F NPWZ1D32A22F
Ref. No. Description Part No.
MPS CBA
Consists of the following:
1ESA12616
SUB CBA (MPS-A)
CRT CBA (MPS-B)
FUNCTION CBA (MPS-C)
JUNCTION-A CBA
JUNCTION-B CBA
----------
----------
----------
----------
----------
Ref. No. Description Part No.
SUB CBA (MPS-A)
Consists of the following:
----------
CAPACITORS
C2530 ELECTROLYTIC CAP. 100µF/35V M CE1GMASDL101
C2532 METALIZED FILM CAP. 0.56µF/200V J CT2D564F7003
C2533# P. P. C A P 0 . 0 1 8 µF/1.6KV J CA3C183VC011
C2534# P. P. C A P. 0 . 0 3 3 µF/200V K CBP2DKD00333
C2535# ALMINIUM ELECTRIC CAPACITOR
UHA1H4R7KHD
CA1J4R7NC235
C2536 FILM CAP.(P) 0.1µF/50V J CMA1JJS00104
C2537 FILM CAP.(P) 0.1µF/50V J CMA1JJS00104
C2538 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C2539 ELECTROLYTIC CAP. 470µF/35V M CE1GMASDL471
C2551 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C2552 FILM CAP.(P) 0.22µF/100V J CMA2AJS00224
C2553 ELECTROLYTIC CAP. 1µF/50V LL CE1JMASLH1R0
C2555 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C2556 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZPDL102
C2559 ELECTROLYTIC CAP. 470µF/35V M CE1GMASDL471
Ref. No. Description Part No.
C2560 FILM CAP.(P) 0.033µF/100V J CMA2AJS00333
C2561 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C2573# FILM CAP.(P) 0.033µF/100V J CMA2AJS00333
C2574# ELECTROLYTIC CAP. 4.7µF/250V M CE2EMASDL4R7
C2577 FILM CAP.(P) 0.018µF/50V J CMA1JJS00183
C2578 ELECTROLYTIC CAP. 47µF/35V M CE1GMASDL470
C2583 ELECTROLYTIC CAP. 2.2µF/100V M CE2AMASDL2R2
C2584# ELECTROLYTIC CAP. 2.2µF/100V M CE2AMASDL2R2
C2586 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C2590 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
C2591# ELECTROLYTIC CAP. 2.2µF/50V M CE1JMASDL2R2
C2592 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C2594 ELECTROLYTIC CAP. 100µF/160V M CE2CMZNDL101
C2603 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C2604 ELECTROLYTIC CAP. 1000µF/6.3V M CE0KMASDL102
C2605 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C2616 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C2629 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C2630 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C2645 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C2670 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C2703 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C3595# PP CAP. 0.0027µF/1.6KV J CT3C272MS039
CONNECTORS
CN2502 TWG CONNECTOR 19P TWG-P19P-A1 J3TWA19TG001
CN2503 TWG CONNECTOR 19P TWG-P19P-A1 J3TWA19TG001
CN2571 CONNECTOR PRINT OSU 5P RTB-1.5-5P (LF) J3RTC05JG002
DIODES
D2530# DIODE ERD07-15L QD4ZERD0715L
D2531# FAST RECOVERY DIODE ERD38-06 QDQZ0ERD3806
D2532 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2536 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2552 DIODE FR104-B NDLZ000FR104
D2555 ZENER DIODE MTZJ-51 QDTZ00MTZJ51
D2572# DIODE FR104-B NDLZ000FR104
D2575# ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D2583 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2584 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2585 ZENER DIODE MTZJT-775.1B QDTB0MTZJ5R1
D2591# ZENER DIODE MTZJT-7736B QDTB00MTZJ36
D2592 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D2595# ZENER DIODE MTZJT-7722A QDTA00MTZJ22
D2596# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2597# SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2598# DIODE FR104-B NDLZ000FR104
D2601 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D2603 ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D2604 DIODE 1N5397-B NDLZ001N5397
D2627 ZENER DIODE MTZJT-773.9B QDTB0MTZJ3R9
D2661 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2662 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2703 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC2551 IC VERTICAL OUTPUT LA78041-E QSZBA0SSY006
IC2602 VOLTAGE REGULATOR TLV1117IDCYRG3 NSZBA0TTY219
IC3603 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
IC3604 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
COILS
L2505 CHOKE COIL 47µH LLBD00PKV022
L2530# LINEARITY COIL STS007 LLBD00ZY2002
L2531 CHOKE COIL ELC18B821LK LLC821KMS001
L2613 INDUCTOR 10µH-K-5FT LLARKBSTU100
Ref. No. Description Part No.
