Magnetek Impulse VG+ series 4 Product Guide

Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 34 of 54
Magnetek, Inc.
Spd Srch at Start
B6-01
(G+ only)
2
0: Speed Search
(Estimated)
Disabled
1: Speed Search
(Estimated)
Enabled
2: Speed Search
(Current Detect)
Disabled
3: Speed Search
(Current Detect)
Enabled
Spd Srch Current
B6-02
(G+ only)
120% -- -- --
Spd Srch Dec
Time
B6-03
(G+ only)
2.0 sec -- -- --
Search Delay B6-05 120% -- -- --
Jump Freq 1 B8-01 0.0 Hz B8-01 0.0 Hz --
Jump Freq 2 B8-02 0.0 Hz B8-02 0.0 Hz --
Jump Freq 3 B8-03 0.0 Hz B8-03 0.0 Hz --
Jump Bandwidth B8-04 1.0 Hz B8-04 1.0 Hz --
Quick Stop 0/1 C1-01
G+: 0
VG+: 1
C1-01
G+: 0
VG+: 1
0: Disabled 0: Disabled
1: Enabled 1: Enabled
Quick Stop Time C1-02 1.0 sec C1-02 1.0 sec --
Reverse Plug 0/1 C1-03 0 C1-03 0
0: Disabled 0: Disabled
1: Enabled 1: Enabled
Rev-Plg Dec Time C1-04 2.0 sec C1-04 2.0 sec --
Rev-Plg Acc Time C1-05 2.0 sec C1-05 2.0 sec --
MicroSpd Gain 1 C2-01 1.00 C2-01 1.00 --
MicroSpd Gain 2 C2-02 1.00 C2-02 1.00 --
Up Limit 1 Speed C3-01 6 Hz C3-01 6.00 Hz --
UL 1 Decel Time C3-02 1.0 sec C3-02 1.0 sec --
UL 2 Stop Time C3-03 1.0 sec C3-03 1.0 sec --
Low Limit 1 Speed C3-04 6 Hz C3-04 6.00 Hz --
LL 1 Decel Time C3-05 1.0 sec C3-05 1.0 sec --
LL 2 Stop Time C3-06 1.0 sec C3-06 1.0 sec --
Lmt Stop Method C3-07 2 C3-07 2
0: Decel to Stop 0: Decel to Stop
1: Coast to Stop 1: Coast to Stop
2: Use B3-03
Method
2: Use B3-03
Method
Parameter
Name
Series 3 Series 4 Comments
No. Default No. Default Series 3 Series 4
