Magnetek Impulse VG+ series 4 Product Guide

Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 38 of 54
Magnetek, Inc.
Hook Height Out
C8-25
(VG+ only)
0
C3-15
(VG+ only)
0
0: At Home = 0V -
U1-50 = 0%, MFAO
= 0V
0: At Home 0% -
U1-50 = 0%, MFAO
= 0V
1: At Home = 10V -
U1-50 = 100%,
MFAO = 10V
1: At Home 100% -
U1-50 = 0%, MFAO
= 0V
Load Float Fault
Revolutions
C8-26
(VG+ only)
4 Revs -- -- --
Digital In Setup C9-01 0 C9-01 0
0: Disabled 0: Disabled
1: G5IN4/C9-02 1: Enabled
2: G5IN4/C9-03 -
06
2: Serial
3: DI-08/C9-03 - 10
DI-08
8 CH Individual
--
4: DI-16/C9-03 - 12
DI-16
Terminals 10 CH
Individual
--
5: Serial/C9-03 - 12
10 CH Individual
--
G5IN4 Setup C9-02 0 C9-02 0F --
DIO Terminal 1 C9-03 0F C9-03 0F --
DIO Terminal 2 C9-04 0F C9-04 0F --
DIO Terminal 3 C9-05 0F C9-05 0F --
DIO Terminal 4 C9-06 0F C9-06 0F --
DIO Terminal 5 C9-07 0F C9-07 0F --
DIO Terminal 6 C9-08 0F C9-08 0F --
DIO Terminal 7 C9-09 0F C9-09 0F --
DIO Terminal 8 C9-10 0F C9-10 0F --
DIO Terminal 9 C9-11 0F C9-11 0F --
DIO Terminal 10 C9-12 0F C9-12 0F --
Load Weight 0/1 C10-01 0 C10-01 0
0: Disabled 0: Disabled
1: Enabled at C5-
04 (Automatic for
the duration of C5-
12 + C5-13) (VG+
only)
1: Enabled (FVC
Only)
2: Enabled at
MFI=5C (VG+ only)
2: Enabled Analog
3: Both Auto &
MFI=5C (VG+ only)
--
4: Analog Input
(Load Cell)
MFAI=16
--
Torque Pri Delay
C10-02
(VG+ only)
200ms -- -- --
LW Display Hold C10-03 0 C10-03 0
0: Hold Display 0: Hold Display
1: Hold Disp 3 sec 1: Hold Disp 3 sec
LW Conversion
C10-04
(VG+ only)
0
C10-04
(VG+ only)
00000 --
Parameter
Name
Series 3 Series 4 Comments
No. Default No. Default Series 3 Series 4
