IMPULSE®•G+ & VG+ Series 3 to Series 4 Transition Guide August 2011
Page 37 of 54
Magnetek, Inc.
Product Transition Guide
IMPULSE
®
•G+ & VG+ Series 4
Torque Comp
Time
C8-01
(VG+ only)
Determined by
Drive
C8-01
(VG+ only)
1.0/1.5 sec --
IFB OK Timer
C8-02
(VG+ only)
Determined by
Drive
C8-02
(VG+ only)
1.0/1.5 sec --
Min Brk Rel Torq
C8-03
(VG+ only)
10%
C8-03
(VG+ only)
10% --
Roll Back Timer C8-04 0.3 sec
C8-04
(VG+ only)
0.3 sec --
Roll Back Count
C8-05
(VG+ only)
800 pulses
C8-05
(VG+ only)
800 pulses --
BE3/Alt Torq T
C8-06
(VG+ only)
0.30 sec
C8-06
(VG+ only)
0.30 sec --
BE3 Det Count
C8-07
(VG+ only)
10 pulses
C8-07
(VG+ only)
10 pulses --
Alt Rev Torq Lim
C8-08
(VG+ only)
25%
C8-08
(VG+ only)
25% --
Zero Speed Level
C8-09
(VG+ only)
1 Hz
C8-09
(VG+ only)
1 Hz --
Load Float Time
C8-10
(VG+ only)
10 sec
C8-10
(VG+ only)
10 sec --
Brake Set Delay C8-11 0.7 sec
C8-11
(VG+ only)
0.7 sec --
BE6 Detect Timer
C8-12
(VG+ only)
5.0 sec
C8-12
(VG+ only)
5.0 sec --
BE6 Max Count
C8-13
(VG+ only)
250 pulses
C8-13
(VG+ only)
250 pulses --
Brake Hold Speed
C8-14
(VG+ only)
0.0%
C8-14
(VG+ only)
5.0 (OLV)
0.0 (FLV)
--
Load Float Ext. T
C8-15
(VG+ only)
10 sec
C8-15
(VG+ only)
10 sec
Init Brk Rel Trq
C8-16
(VG+ only)
100% -- -- --
BE6 Up Speed
C8-17
(VG+ only)
6.00 Hz
C8-18
(VG+ only)
6.00 Hz --
Brake Test Torq
C8-19
(VG+ only)
125%
C8-24
(VG+ only)
125% --
Brake Test Speed
C8-20
(VG+ only)
6 Hz
C8-20
(VG+ only)
6 Hz --
Height Measure
C8-21
(VG+ only)
10000 pulses
C3-13
(VG+ only)
250 --
Hook Height
Home
C8-24
(VG+ only)
0
C3-14
(VG+ only)
0
0: Home = UL2 0: Home = UL2
1: Home = LL2 1: Home = LL2
2: Home = Hook
Height Home
2: Home MFDI
Upper
--
3: Home MFDI
Lower
4: Home = UL3 4: Home = UL3
Parameter
Name
Series 3 Series 4 Comments
No. Default No. Default Series 3 Series 4
