15
46-620 B73 & Series 75 Liquid Level Switches
CARBON STEEL CHAMBERS WITH 2 INCH CONNECTIONS
INCHES MILLIMETERS
Minimum SG given is for single switch units with -1 materials of construction. Consult factory for other configurations.
Switch actuating levels (HL & LL) are given for minimum specific gravity materials of construction –1 and single switch units.
Consult factory for other configurations.
These dimensions increase by 2.19 (55) with Series HS switches with terminal blocks.
5.2 Physical
CARBON STEEL CHAMBERS WITH 1 INCH CONNECTIONS
INCHES MILLIMETERS
CARBON STEEL CHAMBERS WITH 1
1
⁄2 INCH CONNECTIONS
INCHES MILLIMETERS
Min.
SG
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
A B C A B C A B C HL LL A B C A B C A B C HL LL
B75 0.67
8.69 4.34 23.20 12.56 7.6 9 26.07 13.21 7.6 9 27.72
1.48 2.16
221 110 589 319 195 662 336 195 704
37 54
C75 0.55 1.64 2.36 41 59
F75 0.55 10.94 5.88 26.32 14.78 9.19 30.16 15.39 9.19 30.77 0.78 1.36 278 149 669 375 233 766 391 233 782 19 34
G75 0.53
9.50 4.88 24.21 13.31 8.19 28.02 13.96 8.19 28.67
1.31 1.97
241 124 615 338 208 712 355 208 728
33 50
J75 0.48 1.95 2.67 49 67
K75 0.39 11.94 5.88 27.32 15.56 9.19 30.94 16.21 9.19 31.59 1.59 2.21 303 149 694 395 233 786 412 233 802 40 56
L75 0.40 9.50 4.88 24.21 13.31 8.19 28.02 13.96 8.19 28.67 1.50 2.24 241 124 615 338 208 712 355 208 728 38 56
N75 0.32 11.94 5.88 27.32 15.56 9.19 30.94 16.21 9.19 31.59 1.63 2.31 303 149 694 395 233 786 412 233 802 40 58
S75 0.60 Consult Factory n/a n/a Consult Factory n/a n/a
V75 0.74 8.49 4.34 23.27 12.56 7. 68 27.34 13.21 7.68 27.99 1.88 2.63 216 110 591 319 195 694 336 195 711 48 67
Z75 0.68 9.31 4.87 24.16 13.31 8.18 28.16 13.96 8.18 28.81 1.44 2.25 236 124 614 338 208 715 355 208 732 37 57
Min.
SG
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
A B C A B C A B C HL LL A B C A B C A B C HL LL
B73 0.59 6.36 3.34 17.44 9.25 6.25 20.32 9.90 6.25 21.00 1.22 2.10 151 84 442 235 159 515 251 159 532 30 53
B75 0.67
8.69 3.80 22.69 11.56 6.69 25.56 12.21 6.69 26.21
2.56 3.24
221 97 576 294 170 649 310 170 666
65 82
C75 0.55 2.72 3.44 69 87
F75 0.55 10.91 5.33 24.91 13.78 8.19 27.78 14.39 8.19 28.39 1.76 2.35 277 135 633 350 208 706 366 208 721 44 59
G75 0.53
9.44 4.33 23.44 12.31 7.19 26.31 12.96 7.19 26.96
2.25 2.92
240 110 595 313 183 668 329 183 685
57 74
J75 0.48 2.90 3.62 73 91
K75 0.39 11.69 5.33 25.69 14.56 8.19 28.56 15.21 8.19 29.21 2.15 2.77 297 135 653 370 208 754 386 208 742 54 70
L75 0.40 9.44 4.33 23.44 12.31 7.19 26.31 12.96 7.19 26.96 2.45 3.19 240 110 595 313 183 668 329 183 685 62 81
N75 0.32 11.69 5.33 25.69 14.56 8.19 28.56 15.21 8.19 29.21 2.17 2.86 297 135 653 370 208 754 386 208 742 55 72
S75 0.60 11.16 5.33 27.06 Consult Factory 2.13 2.78 283 135 687 Consult Factory 54 70
V75 0.74 9.02 4.15 23.27 11.56 6.68 25.81 12.21 6.68 26.46 2.63 3.38 229 105 591 294 170 656 313 170 672 69 86
Z75 0.68 9.77 4.68 24.16 12.31 7.18 26.70 12.96 7.18 27.35 2.38 3.19 248 119 614 313 182 678 329 182 695 60 81
Min.
SG
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
NPT &
Socket Weld
Flanged
Upper Side/Btm
Flanged
Side/Side
Actuating
Levels
A B C A B C A B C HL LL A B C A B C A B C HL LL
B75 0.67
8.94 4.22 23.06 12.56 7.6 9 26.69 13.21 7. 69 27.34
1.93 2.61
227 107 586 319 195 678 336 195 694
49 66
C75 0.55 1.93 2.61 49 66
F75 0.55 11.06 5.75 26.19 14.78 9.19 29.92 15.39 9.19 30.53 1.08 1.66 281 146 665 375 233 760 391 233 775 27 42
G75 0.53
9.62 4.75 24.09 13.31 8.19 27.75 13.96 8.19 28.42
1.59 2.25
244 121 612 338 208 705 355 208 722
40 57
J75 0.48 2.23 2.95 56 74
K75 0.39 12.06 5.75 27.14 15.56 9.19 30.64 16.21 9.19 31.29 1.77 2.39 306 146 689 395 233 778 412 233 795 44 60
L75 0.40 9.62 4.75 24.09 13.31 8.19 27.75 13.96 8.19 28.42 1.78 2.52 244 121 612 338 208 705 355 208 722 44 64
N75 0.32 12.06 5.75 27.14 15.56 9.19 30.64 16.21 9.19 31.29 1.81 2.49 306 146 689 395 233 778 412 233 306 45 63
S75 0.60 Consult Factory n/a n/a Consult Factory n/a n/a
V75 0.74 8.82 4.22 23.20 12.56 7. 6 8 26.94 13.21 7. 68 27.79 1.94 2.69 224 107 589 319 195 684 336 195 706 49 68
Z75 0.68 9.51 4.75 24.09 13.31 8.18 27.89 13.96 8.18 28.54 1.69 2.59 242 121 612 338 208 708 355 208 725 43 66
