8.13 Instrument Cluster
SET MODE
F EGH DI
S12D01
A CB
A
Tachometer / RPM Gauge
F
Odometer/Tripmeter
B
Warning/Tell tale Lamps
G
Current Gear Display
C
Speedometer
H Set Button
D Mode Button I
Temperature Gauge
E
Fuel Gauge
FEATURES AND CONTROL
