10.2 Center/Side Vents
M
E
N
U
S
E
L
S
R
C
M
U
T
E
P
H
O
N
E
I
N
F
O
B
A
C
K
S12K02
S12K03
A
Adjustable Louvers
B
Thumb Wheel (Open/Close)
Two center vents are located above the audio system on the
instrument panel and two side vents located one each at the left
and right extreme ends of the instrument panel. Both the center
and side vents provide air flow to the front seat passengers. Rotate
the thumb wheel (B) up to open or down to close the air vent. Direct
air to the desired direction by the adjusting louvers (A).
10.3 HVAC Controls
A
/
C
0
1
2
3
4
A
B
C
D
F
E
S12K04
A Air Distribution Control D
AC ON/OFF
B
Blower Speed Control
E
Rear Demist ON/OFF
C
Temperature Control
F
Air Re-circulation
Switch
HEATING, VENTILATION AND AIR-CONDITIONING SYSTEM (HVAC)
