© Copyright Mahindra & Mahindra Ltd. 012016
2-23
2.11 Technical Specifications
Technical Specifications
DIESEL PETROL
ENGINE mFalcon D75 mFalcon G80
Displacement/Cubic Capacity
1198 cc 1198 CC
Type 4 Stroke Turbocharged Compression Ignition 4 Stroke Spark Ignition
Bore x Stroke 76 X 88 mm 76 X 88 mm
No of Cylinders
3 3
Max. Engine Output (kW @ rpm) 57.4 kW @ 3750 rpm 61 KW @ 5500 rpm
Max. Torque (Nm @ rpm) 190 Nm @ 1750 to 2250 rpm 115 Nm @ 3500 to 3600 rpm
CLUTCH
Type Single plate Dry Diaphragm Type
TRANSMISSION
Type
Manual Transaxle
No. of Gears 5 Forward + 1 Reverse
GEAR RATIOS
I 3.909: 1 3.909: 1
II 2.100: 1 2.100: 1
III 1.481: 1 1.481: 1
IV 1.094: 1 1.094: 1
V 0.838: 1 0.838: 1
Reverse 3.769 : 1
GENERAL
