5.3 Front Foldable Armrests (if equipped)
Front middle seat backrest can be folded and utilized as arm rest
for both front occupants.
Pull the lock upwards and fold the middle seat backrest to the
required position
S12E07
S12E06
To straighten the middle seat backrest, pull the lock upwards and
lift the backrest to the vertical position
S12E08
S12E09
