4 INSTRUMENT CLUSTER OVERVIEW
4.1 Instrument Cluster (K2/K2+/K4/K4+)
SET MODE
S12D04
F EGH DI
A CB
A
Tachometer / RPM Gauge
F
Odometer/Tripmeter
B
Warning/Tell tale Lamps
G
Gear Display
C
Speedometer
H Set Button
D Mode Button I
Temperature Gauge
E
Fuel Gauge
