2-12
© Copyright Mahindra & Mahindra Ltd.012016
Fuse No
Fuse Rating
Circuit
F18 10A GNS/ FAN/AC COMP/ FUEL
PUMP RELAY
F19 10A ECU SUPPLY- 2
F20 10A TRI.PR.SW/ ESS
F21 10A HFM
F22 10A BRAKE LAMP
F23 15A EGR\ BOOST\ HPP
F24 10A SPARE
F25 15A HEAD LAMP HIGH
F26 10A AC COMPRESSOR
F27 15A HEAD LAMP LOW
F28 20A FUEL PUMP
F29 15A HORN
F30 BLANK
F31 5A DRL
F32 15A SPARE
Relay No
Circuit
R1 STARTER
R2 GNS
R3 ELECTRIC FAN-HIGH
R4 ELECTRIC FAN-LOW
R5 AC COMPRESSOR
R6 HEAD LAMP HIGH
R7 ECU MAIN RELAY
R8 HORN
R9 HEAD LAMP LOW
R10 FUEL PUMP RELAY
GENERAL
