Relay No
Circuit
R15 BLANK
R16 REAR DE- MISTER RELAY
2.6.3 Battery Mounted Fuse Box
The battery mounted fuse box is connected to the positive terminal
of the battery. The battery mounted fuse box provide short circuit
protection for Battery to Main engine compartment fuse box &
Electric cooling fan.
Battery mounted fuse box consist of following fuses:
• Brass fuse link
• Bus bar fuse - 80 A
• Cooling fan fuse – 60 A
Do not connect battery terminals with opposite polarity, it will
lead to alternator failure
2.6.4 Glow Plug Relay Box (Only for Diesel)
Glow plug relay box is located in front of the Engine compartment
fuse box on the battery mounting bracket.
