Repair Manual MAN-00190
THAR CRDe BS-IV MAY 2012/Rev 1
The repair methods given by the manufacturer in this document are based on the technical specifications, current at the time of release. The methods may be modified as a result of changes introduced by the
manufacturer in the production of the various component units and accessories from which the vehicles are manufactured. The reproduction, translation, transmission, in part of or whole of the present
document, are prohibited without the prior written consent of Mahindra & Mahindra Ltd. The use of this document by any person other than the trained personnel, at the Authorized Service Centre of Mahindra
& Mahindra Ltd., will amount to unauthorized use and shall be liable for penalty/prosecution© 2012 Mahindra & Mahindra Ltd.
Technical Specification
Description Specification
Configuration Part time, Single Offset
Rear output configuration Circular flange
Front output configuration Fixed yoke
Input configuration Female spline
Offset hand Right hand
Lubrication System Force lubrication by Gear rotor pump
Fluid type Castrol ATF ‐ TQ
HPCL ATF ‐ A
IOC Servo Transfluid ‐A
Chemoleum ‐ A
Housing Material Aluminum
Dry weight in kgs 30 Kgs. Aprox.
Fluid Capacity in liters 1.2
Shift Pattern 2H ‐ 4H ‐ 4L
4WH shift on the fly Optional
Shift Control Selector switch
Torque Specification
Description Torque in Nm
Level oil drain plug
34 ± 6
Rear flange nut
