MAI INTERNATIONAL

GmbH

SPARE PARTS "FIGURE D"

Pos. P/N Description

1 100252 Glycerin gauge 6 bar

2 153610 Water flowmeter 1/2" 2500l

2.01 w/o Fig. 153762 Water flowmeter 1/2" with cable

2.02 w/o Fig. 153642 Connection cable for water flow meter

3 100391 Water dosing valve 3/4" 110 MS 5

3.01 w/o Fig. 100269 Preset disk dosing valve 1/2"

4 151124 Drain valve 3/8" external thread

5 152559 Solenoid valve NC 1/2" NW13 42 V /50Hz

5.01 w/o Fig. 153761 Solenoid valve with cable NC 1/2" NW13 42V/50Hz

6 100134 Coupling GEKA 3/4" AG brass

7 151000 Filter 3/4" brass

7.01 w/o Fig. 151300 Screen mesh netting 0.35 mm

8 153645 Brass filter cup with proximity switch

9 152787 Pressure reducing valve D06FN 1/2" with proximity switch

9.01 w/o Fig. 153760 Brass filter cup with proximity switch and cable

9.02 w/o Fig. 102746 O-ring
